Atlas RL SP

ATLAS RL SP

Atlas RL SP provides a practical traction MRL solution for commercial and public buildings. Designed to serve rated loads of up to 1000 kg, it can be customized to meet specific requirements, including anti-vandal, firefighting, and earthquake-resistant configurations.

Atlas RL SP delivers exceptional performance with remarkably low energy consumption, while its Destination Control feature significantly reduces passenger waiting times.

Spatial efficiency

Optimized space efficiency for high passenger flow, allowing larger car installations within a standard shaft.

Stopping accuracy

Thanks to its gearless motor and state-of-the-art inverter, Atlas RL SP delivers exceptional stopping accuracy within 2mm.

Safe door closing

Atlas RL SP is equipped with light curtains to provide additional protection to the passenger when the car doors are closing.

Extra safety features

The safety of the lift is enhanced through features designed for vandal resistance, firefighting, and earthquake protection.

Emergency evacuation

In the event of a power failure, the emergency evacuation system safely transports passengers to the nearest floor, where the doors automatically open for exit.

Reduced waiting times

The Destination Control System minimizes waiting times by efficiently managing multiple calls, ensuring passengers are transported quickly and smoothly.

Minimum Pit Depth:

for v≤ 1.0m/s 1150
for v≤ 1.75m/s 1300

Millimeters

Minimum Clear Headroom:

for v≤1.0 m/s 3400
for v≤1.75m/s 3650
for v≤1.0 m/s 3800
for v≤1.75m/s 4065

Millimeters

Max Rated Speed:

1.0 / 1.75

Meters per second

Complies With:

EN81-1, EN81.20

Directives & standards

Suspension:

2 : 1

Configuration

Rated Load:

400 - 1000

Kilograms

TECHNICAL SPECIFICATIONS
